EPIDEMIOLOGY OF DRY AMD AND GA

A review of data, demographics, and risk factors.BY RISHI P. SINGH, MD Age-related macular degeneration (AMD) is the leading cause of blindness among white Americans,¹ and is the second-leading cause of blindness among American Hispanics.² Classification of early, intermediate, and advanced stages of AMD is well understood, and disease in the advanced state is classified as either central geographic atrophy (GA) or neovascular AMD.^3,4 Anti-VEGF agents are effective at  treating patients with neovascular AMD, and there are no approved therapies for intermediate dry AMD or GA. The dearth of treatment options for GA is particularly concerning when one notes that the Age-Related Eye Disease Study (AREDS) group found that a majority of patients (53.9%) who progressed to advanced AMD during a 10-year study period demonstrated central GA.⁵  Approximately 80 to 95% of patients with AMD develop some atrophic form of the disease, and approximately 30% of them progress to GA.^6,7 Clinically, GA is defined by the presence of irreversible central scotoma, which present as areas of depigmentation of the retinal pigment epithelium (RPE) with sharp-bordered margins (Figure 1). Classification schemes, which are discussed in this article, guide categorizing disease severity.

Figure 1. Dense, irreversible scotomas and areas of complete depigmentation of the RPE with sharp margins are hallmark clinical presentations of GA.

GROWING NEED An estimated 2 million patients had AMD in 2010 in the United States. That number is expected to grow to 3.6 million and 5.4 million in 2030 and 2050, respectively.⁸ Globally, 196 million patients and 288 million patients are expected to have any form of AMD in 2020 and 2040, respectively.⁷ GA accounts for approximately 35% of advanced AMD cases, and more than 5 million patients have the disease globally.^7,9 Given the age-related nature of the disease, it is unsurprising that increased age is associated with advanced risk—and that longer life expectancies will lead to higher rates of disease. Indeed, prevalence of AMD approximately quadruples every 10 years of age after age 50.9 Of the 5 million patients with GA globally, 4.4% of them are older than 85, and 22% are over 90.⁹CLASSIFICATION OF AMDAREDS Classification A number of classification schemes exist for AMD. One of the major contributions of the AREDS was establishing the parameters around detection and classification of AMD. The AREDS classification scheme developed in 2005 divided AMD disease presentation into four categories,⁴ the defining features of which are explained in Table 1.

The AREDS classification system can be used to establish a severity score. One severity score point is assigned to each condition in the classification scheme, and both eyes’ scores are combined. For example, a patient with drusen and pigment changes in both eyes would have a severity score of 4. A severity score based on the AREDS classification system can be used to establish a 5-year risk of progression to late AMD.⁴ The risk of 5-year progression vis-à-vis AREDS severity score can be seen in Figure 2. In my experience, patients find this scoring system easy to understand.

Figure 2. A 5-year risk of developing late AMD can be calculated by using a severity score point system in the AREDS classification scheme.

Beckman Committee Classification The Beckman Committee classification system was published in 2013.³ It is a modified version of the AREDS classification scheme. This system’s criteria for disease classification is outlined in Table 2.

The Beckman Committee classification scheme determined that small drusen should be termed drupelets, and that they are normal signs of aging. In this system, the presence of drupelets does not indicate the presence of AMD. Clinically, the Beckman Committee classification system may be used in patients who present with small drusen but no pigmentary abnormalities. In 2018, the Classification of Atrophy Meetings (CAM) consensus used the Beckman Committee classification scheme to classify atrophy associated with AMD.¹⁰ The list of abbreviations used by the CAM consensus are listed in Table 3. This nomenclature is often used in the setting of a reading center rather than in the clinic.

What is the value of these additional classifications of atrophy? In a recent presentation at EURETINA, a post hoc analysis of the FILLY study demonstrated that pegcetacoplan therapy impacts the progression of nascent GA (eg, iRORA), the earlier stage of disease that precedes atrophy, in areas of the retina outside of GA lesions.¹¹QUALITY OF LIFE Keeping in mind how visual impairment affects patients’ lives is paramount to providing care. Patients with GA find daily living routines disrupted. The inability to dark adapt (ie, transition rapidly from dark to light environments, and vice versa) is among the first complaints I receive from patients with AMD. Impairments to leisure activities (reading, sports), social activities (friendly gatherings, family events) and transportation (ability to drive) often follow.¹² Among patients with GA who have a driver’s license, 50% reported discomfort with daytime driving and 88% reported discomfort with nighttime driving.¹³ Patients consider AMD among the most disruptive diseases that could affect quality of life.¹⁴ Patients would prefer to experience myocardial infarction rather than 20/40 VA related to AMD, and have determined that dialysis has a higher quality-of-life score than AMD associated with vision worse than 20/200. ASSESSEMENTS FOR VISUAL ACUITY Many retina specialists rely on metrics such as best corrected visual acuity on a Snellen chart and visual acuity score on an Early Treatment of Diabetic Retinopathy Study chart. Amsler grids and contrast sensitivity testing may be used to evaluate quality of vision in some patients. Reading speed tests may assist in evaluating functional vision. Microperimetry is used to measure retinal function in eyes with GA (Figure 3).¹⁵ Functional progression of GA and area of scotomas can be evaluated on microperimetry. Visual sensitivity can be mapped to a fundus photo and compared with images attained with other modalities. In this modality, stimuli can be used to identify very specific areas of the retina where the patient has functional issues.

Figure 3. Retinal function in patients with GA can be assessed on microperimetry. Here, a patient’s progression can be observed over a 2-year period. These images may be mapped onto fundus photos and compared with imaging reports from other modalities.

RISK FACTORS As one might expect with an age-related disease, aging is the leading risk factor for developing advanced AMD and GA.⁸ Factors outside of patient control include gender, family history, and genetic predisposition.⁸ Smoking and diet, however, are two factors that patients can control. Smoking history and status as a current smoker are associated with increased risk of AMD progression.¹⁶ Smokers are more likely than nonsmokers to develop GA.¹⁷ Patients consuming a Mediterranean diet (ie, nutrient-rich foods such as fruits, vegetables, legumes, and fish) have reduced risk for advanced AMD.¹⁸ White Americans develop AMD at a significantly higher rate than other demographics starting at age 75 (Figure 4).⁸ Ocular factors such as aphakia and hyperopia and systemic factors such as cardiovascular disease are also risk factors for AMD development.¹⁹

Figure 4. White Americans develop AMD at twice the rate of other racial demographics starting at age 75, and at nearly 14 times the rate of other racial demographics starting at age 80.

CONCLUSION An understanding of the pathophysiology of AMD and GA may help clinicians understand the disease, and knowing how the disease affects patients' quality of life can guide treatment decisions. In the following articles in this series, Nathan Steinle, MD, explores GA’s pathophysiology and natural history, and Charles C. Wykoff, MD, PhD, details treatment options and pipeline drug candidates. 1. Congdon N, O’Colmain B, Klaver CCW, et al. Eye Diseases Prevalence Research Group. Causes and prevalence of visual impairment among adults in the United States. ArchOphthalmol. 2004;122(4):477-485.2. US Eye Disease Statistics. American Academy of Ophthalmology. Available at: www.aao.org/eye-disease-statistics. Accessed September 30, 2020.3. Ferris FL 3rd, Wilkinson CP, Bird A, et al. Beckman Initiative for Macular Research Classification Committee. Clinical classification of age-related macular degeneration. Ophthalmology. 2013;120(4):844-851.4. Ferris FL 3rd, Davis MD, Clemons TE, et al. A simplified severity scale for age-related macular degeneration: AREDS Report No. 18. Arch Ophthalmol. 2005;123(11):1570-1574.5. Chew EY, Clemons TE, Agron E, et al. Age Related Eye Disease Study Research Group. JAMA Ophthalmol. 2014;132(3):272-277.6. Lindblad AS, Lloyd PC, Clemons TE, et al; Age Related Eye Disease Study Research Group. Change in area of geographic atrophy in the Age-Related Eye Disease Study: AREDS report number 26. Arch Ophthalmol. 2009;127:1168-1174.7. Wong WL, Su X, Li X, et al. Global prevalence of age-related macular degeneration and disease burden projection for 2020 and 2040: a systematic review and meta-analysis. LancetGlob Health. 2014;2:e106-e116.8. National Institutes of Health. Facts About Age-Related Macular Degeneration. Available at: nei.nih.gov/health/maculardegen/armd_facts. Updated July 17, 2019. Accessed September 15, 2020.9. Rudnicka AR, Jarrar Z, Wormald R, et al. Age and gender variations in age-related macular degeneration prevalence in populations of European ancestry: a meta-analysis. Ophthalmology. 2012;119(3):571-580.10. Sadda SR, Guymer R, Holz FG, et al. Consensus definition for atrophy associated with age-related macular degeneration on OCT: Classification of atrophy report 3 [published correction appears in Ophthalmology. 2019;126(1):177]. Ophthalmology. 2018;125(4):537-548.11. Apellis Announces Late-Breaking Presentation of Targeted C3 Therapy Pegcetacoplan in Patients with Geographic Atrophy (GA) at EURETINA 2020 [press release]. Apellis Pharmaceuticals; Waltham, MA; September 21, 2020.12. Nielsen JS, Singh RP, Patel SS, et al. How Much Do We Know About the Economic and Patient-Reported Burden of Geographic Atrophy? Talk presented at EURETINA 2016, Copenhagen, September 11, 2016.13. Patel PJ, Ziemssen F, Ng E, et al. Burden of illness in geographic atrophy: a study of vision-related quality of life and health care resource use. Clin Ophthalmol. 2020;14:15-28.14. Yuzawa M, Fujita K, Tanaka E, et al. Assessing quality of life in the treatment of patients with age-related macular degeneration: clinical research findings and recommendations for clinical practice. Clin Ophthalmol. 2013;7:1325-1332.15. Sadda SR, Chakravarthy U, Birch DG, et al. Clinical endpoints for the study of geographic atrophy secondary to age-related macular degeneration. Retina. 2016;36(10):1806-1822.16. Evans JR, Fletcher AE, Wormald RPL. 28,000 cases of age-related macular degeneration causing visual loss in people aged 75 years and above in the United Kingdom may be attributable to smoking. Br J Ophthalmol. 2005;89(5):550-553.17. Age-Related Eye Disease Study Research Group. Risk factors associated with age-related macular degeneration. A case-control study in the age-related eye disease study: Age-Related Eye Disease Study report number 3. Ophthalmology. 2000;107(12):2224-2232.18. Merle BMJ, Colijn JM, Cougnard-Gregoire A, et al. EYE-RISK Consortium. Mediterranean diet and incidence of advanced age-related macular degeneration: the EYE-RISK consortium. Ophthamology. 2019;126(3):381-390.19. Macular Degeneration. American Optometric Association. Available at: www.aoa.org/healthy-eyes/eye-and-vision-conditions/maculardegeneration?sso=y. Accessed September 30, 2020.

---

PATHOPHYSIOLOGY AND NATURAL HISTORY OF GA

A review of data shows us what we know about the course of this blinding disease. BY NATHAN STEINLE, MD By better understanding the pathophysiology of geographic atrophy (GA), clinicians and researchers can build strategies for treatment. PATHOPHYSIOLOGY OF GA In patients with GA, complement deposition between the retinal pigment epithelium (RPE) and Bruch membrane occurs,¹ followed by a loss of complement regulation and a breakdown of the blood-retinal barrier.² Drusen, which are extracellular deposits of lipid- and protein-rich debris, are the first clinically detectable evidence of age-related macular degeneration (AMD).² RPE secretions are a major source of drusen.³ Drusen are approximately 40% lipid, along with lipofuscin, albumen, immunoglobulins, and amyloid.² Complement factors C1q, C3, C5, and C5b–9 have also been detected in drusen.² The RPE is essential to maintaining a healthy retina. The RPE facilitates the transportation of nutrients to photoreceptor layers, phagocytizes waste, and is a source of tropic factors such as VEGF-A.² The RPE also maintains the integrity of the outer retinal blood barrier and produces pigment to absorb scattered light.²The Complement Cascade The complement cascade is part of the immune system involved in detection and removal of foreign pathogens. Research suggests that overactivation of the complement cascade may contribute to the development of AMD via inflammation, phagocytosis, and the creation of membrane attack complex (MAC).⁴ Three pathways activate the complement cascade: the classical pathway, the lectin pathway, and the alternative pathway (Figure 1). All three of these pathways activate C3, leading to the activation of (in order) C3b, C5, and C5b, which in turn leads to the creation of MAC.⁴ Cell death occurs in the presence of MAC. Researchers’ understanding of the complex nature of the complement system—it involves approximately 30 proteins—is growing, and it may serve as a useful target for GA therapy.

Figure 1. Any of the three complement pathways activate C3, leading to a cascade that results in the creation of MAC. Approximately 30 proteins are involved in this cascade.

Staining for C3 and C5 beneath the RPE and in drusen on confocal immunofluorescence microscopy illustrates the degree to which deposits accumulate in patients with GA (Figure 2).^5,6 This anatomic imaging data supports the claim that complement activation is involved in the progression of GA.

Figure 2. Confocal immunofluorescence microscopy illustrates the degree to which C3 and C5 accumulate in the sub-RPE space and in drusen. C3 is illuminated in green in Figure 2A and 2B, and C5 is illuminated in red in Figure 2C.

Genetic Factors The risk alleles CFH and ARMS2 appear to share a common pathway in the pathogenesis of AMD.⁷ These two risk alleles are independently associated with complement activation. Activation of the alternative pathway; elevated levels of C3d, C5a, and complement factor B; and increased ratios of C3d to C3 are all associated with AMD.⁷ Approximately 40 genes are implicated in development of GA, accounting for about 50% of the overall risk of  development of advanced disease.^8,9 Researchers have noted complement factor H’s association with AMD development,¹⁰ along with complement factor B, complement factor I, C2, C3, and C9. CLINICAL PRESENTATION OF GA Clinically, GA presents as round or oval patches of atrophy of the retina, RPE, and underlying choroid.^11,12 In some cases, patches grow in size and number; in other cases, patches join together to become larger atrophic lesions. Although GA tends to be bilateral, asymmetric cases are common. Several modalities are useful for imaging patients with GA. These include fundus color photography (CFP), fundus autofluorescence (FAF), and optical coherence tomography (OCT). Color Fundus Photography CFP is easy to obtain, is noninvasive, and is a practical tool for imaging patients with early AMD.¹³ Drusen and pigmentary abnormalities can be detected on CFP, and lesion size in GA patients can be evaluated on CFP (Figure 3).¹⁴ Circular lesions with demarcated edges that occur alongside partial or complete depigmentation of the RPE are hallmarks of GA lesions.¹⁵ Because CFP may be used to evaluate drusen size and volume and the presence of GA lesions, it is an effective imaging modality for clinicians who employ the Age-Related Eye Disease Study classification system¹⁶ or the Beckman Committee classification system,¹⁷ both of which  were discussed in the preceding article by Rishi P. Singh, MD.

Figure 3. CFP can be used to image patients with GA at all stages of disease. CFP’s ability to follow drusen makes it a particularly useful tool for classifying disease severity and for tracking progression.

Fundus Autofluorescence FAF may be used to track GA growth and the extent of RPE damage, and to map areas of lipofuscin deposits, which are autofluorescent in nature. GA lesions themselves are hypoautofluorescent.¹³ In a healthy retina, lipofuscin autofluorescence is distributed uniformly in a pattern that diminishes toward the fovea. No hyperautofluorescent material is observed in the junctional zone (Figure 4A). Focal lipofuscin patterns are observed in some patients as small, individual hyperautofluorescent spots on the periphery of a GA lesion (Figure 4B). A pathophysiologic change is likely to occur near those spots. GA lesions surrounded by a continuous line of hyperautofluorescent lipofuscin are called banded patterns (Figure 4C). The term diffuse trickling is used to describe cases of GA that do not have sharp lesion borders but show evidence of hyperautofluorescent lipofuscin graded patterns (Figure 4D). Classification of FAF perilesional patterns inform clinicians about a GA patient’s likely progression,^18,19 ie, which focal, banded, and diffuse GA patterns increase the likelihood of GA progression. Findings from Holz et al are outlined in the Table.¹⁸

Figure 4. (A) A healthy retina shows a uniformly distributed pattern of hyperautofluorescent spots. (B) Focal patterns show hyperautofluorescent spots on the border of a GA lesion. (C) Banded patterns of hyperautofluorescent spots encircling GA lesions are sometimes observed, as are less-defined patterns of GA lesions and hyperautofluorescent material (D).

Optical Coherence Tomography OCT imaging detects AMD-related damage to the retina by depicting loss of RPE and choriocapillaris. ²⁰ Loss of  photoreceptors occurs with GA advancement, and the diffuse thinning associated with GA can be observed on OCT.²¹ The specificity of OCT matches that of CFP for detecting atrophy.²²NATURAL HISTORY The Proxima A and Proxima B studies observed patients with GA for 2 years.²³ Mean change in GA area increased during the 2-year period (Figure 5). Best corrected visual acuity results steadily declined for these patients, with patients in Proxima A losing approximately 13.9 letters at 24 months (Figure 6).²³ At 24 months, patients in Proxima A and Proxima B lost approximately 7.6 to 8.4 letters of low-luminance visual acuity (LLVA).²³ Low luminance deficit (calculated by subtracting LLVA from BCVA) fell by approximately 5.8 letters in Proxima A and by 1.8 to 4.0 letters in Proxima B.

Figure 5. The Proxima A and Proxima B studies found that mean GA lesion area grew over the course of 2 years.

Figure 6. The Proxima A and Proxima B studies found that patients lost significant vision over 2 years.

BIGGEST RISK FACTORS FOR PROGRESSION OFGEOGRAPHIC ATROPHY Patients with large baseline lesions and multifocal lesions are more likely to experience GA progression compared  qith patients without such baseline characteristics.²⁴ Patients with FAF lipofuscin patterns categorized as banded or diffuse trickling are more likely to experience GA progression compared with those who have no evidence of lipofuscin or  local patterns on FAF.²⁴ Patients with extrafoveal lesions are likely to experience progression into the periphery and are more likely to progress at faster rates than those with subfoveal lesions.²⁴CONCLUSION There is no therapy approved by the US FDA for the treatment of GA. However, a number of pipeline candidates are under investigation. Charles C. Wykoff, MD, PhD, details those in the next article. 1. Age-Related Eye Disease Study Research Group. A randomized, placebo-controlled, clinical trial of high-dose supplementation with vitamins C and E, beta carotene, and zinc for age-related macular degeneration and vision loss: AREDS report no. 8. Arch Ophthalmol.2001;119(10):1417-1436. Erratum in Arch Ophthalmol. 2008;126(9):1251.2. Ambati J, Atkinson JP, Gelfand BD. Immunology of age-related macular degeneration. Nat Rev Immunol. 2013;13(6):438-451.3. Wang L, Clark ME, Crossman DK, et al. Abundant lipid and protein components of drusen. PLoS One. 2010;5:94):e10329.4. Xu H, Chen M. Targeting the complement system for the management of retinal inflammatory and degenerative diseases. Eur J Pharmacol. 2016;787:94-104.5. Anderson DH, Radeke MJ, Gallo NB, et al. The pivotal role of the complement system in aging and age-related macular degeneration: hypothesis re-visited. Prog Retin Eye Res. 2010;29(2):95-112.6. Anderson DH, Mullins RF, Hageman GS, et al. A role for local inflammation in the formation of drusen in the aging eye. Am J Ophthalmol. 2002;134(3):411-431.7. Smailhodzic D, Klaver CCW, Klevering BJ, et al. Risk alleles in CFH and ARMS2 are independently associated with systemic complement activation in age-related macular degeneration. Ophthalmology. 2012;119(2):339-346.8. Handa JT, Rickman CB, Dick AD, et al. A systems biology approach towards understanding and treating non-neovascular age-related macular degeneration. Nat Commun. 2019;10(1):3347.9. Fritsche LG, Igl Wilmar, Bailey JNC, et al. A large genome-wide association study of age-related macular degeneration highlights contributions of rare and common variants. Nat Genet. 2016;48(2):134-143.10. Klein RJ, Zeiss C, Chew EY, et al. Complement factor H polymorphism in age-related macular degeneration. Science. 2005;308(5720):385-389.11. Rosenfeld PJ. Emerging Therapies for Dry AMD. Talk presented at Retina 2015; Grand Wailea Resort, Maui, Hawaii January 20, 2015.12. Quillen DA. Common causes of vision loss in elderly patients. Am Fam Physician. 1999;60(1):99-108.13. Sadda SR, Chakravarthy U, Birch DG, et al. Clinical endpoints for the study of geographic atrophy secondary to age-related macular degeneration. Retina. 2016;36(10):1806-1822.14. Schmitz-Valckenberg S, Sahel JA, Danis R, et al. Natural history of geographic atrophy progression secondary to age-related macular degeneration (geographic atrophy progression study). Ophthalmology. 2016;123(2):361-368.15. Lindblad AS, Lloyd PC, Clemons TE, et al. Age Related Eye Disease Study Research Group. Change in area of geographic atrophy in the Age-Related Eye Disease Study: AREDS report number 26. Arch Ophthalmol. 2009;127:1168-1174.16. Ferris FL 3rd, Davis MD, Clemons TE, et al. A simplified severity scale for age-related macular degeneration: AREDS Report No. 18. Arch Ophthalmol. 2005;123(11):1570-1574.17. Ferris FL 3rd, Wilkinson CP, Bird A, et al. Beckman Initiative for Macular Research Classification Committee. Clinical classification of age-related macular degeneration. Ophthalmology. 2013;120(4):844-851.18. Holz FG, Bindewald-Wittich A, Fleckenstein MD, et al. FAM-Study Group. Progression of geographic atrophy and impact of fundus autofluorescence patterns in age-related macular degeneration. Am J Ophthalmol. 2007;143(3):463-472.19. Jeong YJ, Hong H, Chung JK, et al. Predictors for the progression of geographic atrophy in patients with age-related macular degeneration: fundus autofluorescence study with modified fundus camera. Eye (Lond). 2014;28(2):209-18.20. Yehoshua Z, Rosenfeld PJ, Gregori G, et al. Progression of geographic atrophy in age-related macular degeneration imaged with spectral domain optical coherence tomography. Ophthalmology. 2011;118(4):679-686.21. Fleckenstein M, Adrion C, Schmitz-Valckenberg S, et al. FAM Study Group. Concordance of disease progression in bilateral geographic atrophy due to AMD. Invest OphthalmolVis Sci. 2010;51(2):637-642.22. Williams DF, Yaspan B, Zhengrong L, et al. Lampalizumab (anti-factor D) in Geographic Atrophy: the MAHALO Phase II Results. Presented at: 2013 American Society of Retina Specialists (ASRS) Meeting; August 27, 2013; Toronto, ON, Canada.23. Holekamp N, Wykoff CC, Schmitz-Valckenberg S, et al. Natural history of geographic atrophy secondary to age-related macular degeneration: results from the prospective Proxima A and B clinical trials. Ophthalmology. 2020;127(6):769-783.24. Fleckenstein M, Mitchell P, Freund KB, et al. The progression of geographic atrophy secondary to age-related macular degeneration. Ophthalmology. 2018;125(3):369-390.

---

THE GEOGRAPHIC ATROPHY PIPELINE

Successful targeting of the complement cascade appears to be emerging as an effective therapeutic option for patients. BY CHARLES C. WYKOFF, MD, PHD Many retina specialists would argue that nonexudative age-related macular degeneration (AMD) and geographic atrophy (GA) are the largest unmet needs in the clinic. There are no commercially available therapies for this disease despite numerous attempts from innovators to have a drug reach a phase 3 primary endpoint. Still, a number of drug candidates are in the pipeline. We will review past andcurrent drug candidates here. As Nathan Steinle, MD, explained in the previous article, the complement cascade may be an effective target for GA therapy. A series of trials have attempted to intervene at the complement level. SHOTS ON GOAL, BUT NO SUCCESS In 2013, the investigator-sponsored COMPLETE study explored whether intravenous infusion of the anti-C5 monoclonal antibody eculizumab would affect the rate of GA growth in approximately 30 patients who were actively treated over 24 weeks. Patients in the treatment group did not experience a significantly different rate of GA growth compared with sham. LFG316 is a monoclonal antibody that targets C5. In 2016, investigators found that LFG316 did not significantly reduce GA lesion size or improve visual acuity in approximately 150 patients.¹ Lampalizumab is an antibody fragment targeting complement factor D, which is the rate-limiting enzyme of the alternative complement pathway, upstream of C3. In the phase 3 Chroma and Spectri trials, 1,881 patients were assigned to receive treatment or sham every 4 or 6 weeks. In 2017,  researchers announced that at 1 year, no significant differences were observed in GA lesion area growth among trial’s two intervention arms compared with the pooled sham arms.²A PROMISING PIPELINE Several drug candidates have shown potential to have a therapeutic effect. Pegcetacoplan Pegcetacoplan is pegylated, highly selective, bicyclic peptide that prevents C3 cleavage into C3a and C3b. Reduction of C3b, in turn, leads to cessation of the complement cascade from propagating downstream, and also results in decreased levels of C5a and C5b, which can function as inflammatory mediators. The safety and efficacy of pegcetacoplan was evaluated in the single-masked phase 2 FILLY trial. Patients were randomly assigned to 15 mg pegcetacoplan or sham monthly or 15 mg pegcetacoplan or sham every other month (EOM). The primary endpoint of reduction in growth of GA area was assessed at 12 months, and the total duration for the trail was 18 months. Neither drug nor sham were administered between months 12 and 18. In FILLY, patients who were dosed with pegcetacoplan monthly or EOM had a reduction in GA growth at 1 year compared with sham (Figure 1).³ Patients in the monthly arm had a 29% reduction (P = .008) and those in the EOM had a 20% reduction (P = .067); the prespecified P value in FILLY was 0.1. Patients in FILLY who had bilateral GA received treatment in only one eye. In these patients, researchers compared fellow eyes to study eyes (Figure 2). At 12 months, no differences were detected in the sham groups between eyes that received sham treatment and fellow eyes.  A 10% (P > .1) difference in GA lesion growth was detected in eyes that received EOM pegcetacoplan treatment compared monthly pegcetacoplan therapy, the difference was 23% (P = .083) between pegcetacoplan treated and fellow eyes.³

Figure 1. The phase 2 FILLY study found that GA lesion growth at 1 year was reduced by 29% and 20% in patients who were treated with pegcetacoplan monthly or EOM, respectively, compared with sham. Both reductions were statistically significant.

Figure 2. Patients with bilateral GA at baseline who received treatment monthly with pegcetacoplan experienced a 23% difference in GA lesion growth at 1 year compared with their untreated contralateral control eye.

During the first 6 months of the FILLY study, patients in all groups experienced the same rate of GA lesion growth. During the second 6 months a 33% (P = .01) difference was noted in the EOM group compared with sham, and a 47% (P < .001) difference was noted in the monthly group. During the final 6 months of the study (during which no intervention was given), differences of 9% and 12% were detected in the EOM and monthly groups compared with sham; neither value was statistically significant.³ No difference in visual acuity was noted at the 12- or 18- month endpoints in FILLY.³ Decline of visual acuity at a rate of approximately 1 line per year is consistent with data from the GA natural history studies Proxima A and B.⁴ It should be noted that the study investigators enrolled patients with GA lesions that could be either foveal-involving of nonfoveal-involving. Development of exudative AMD at 18 months occurred in 10.5% of patients. A dose-dependent relationship with pegcetacoplan exposure and the development of investigator-determined exudative AMD development was observed, as 1% of sham patients, 9% of EOM patients, and 21% of monthly patients showed evidence of exudative AMD at 18 months. Patients with exudative AMD in the contralateral untreated eye were more likely to experience bilateral exudative AMD at 18 months than patients without contralateral exudative AMD. The DERBY and OAKS trials, two multinational phase 3 trials assessing the safety and efficacy of pegcetacoplan for the treatment of GA are fully enrolled and primary results at 12 months are expected in 2021. Avacincaptad Pegol Avacincaptad pegol works further downstream than pegcetacoplan to inhibit cleavage of C5, preventing the accumulation of C5a and C5b and the resulting creation of MAC. Avacincaptad is a pegylated 39-base RNA aptamer. A double-masked, phase 2b/3 clinical trial (retroactivelynamed the GATHER1 trial) assessing the safety and efficacy of avacincaptad for the treatment of GA was divided into two  parts (parts 1 and 2), with a total of 286 patients among all arms. In part 1, patients received either 1 mg or 2 mg avacincaptad monthly or sham. In part 2, patients received 2 mg avacincaptad plus sham each month, two doses of 2 mg avacincaptad each month (totaling 4 mg avacincaptad each month), or two doses of sham. The primary endpoints in both study parts were 12 months.⁵ At 12 months, in part 1, patients who received monthly 2 mg avacincaptad therapy each month experienced a 27% reduction in GA growth area at 1 year compared with sham (P = .007) (Figure 3). In part 2, patients who received 4 mg total of avacincaptad (ie, two doses of 2 mg avacincaptad) each month experienced a 28% reduction in GA growth area at 1 year (P = .005).

Figure 3. Both parts of a phase 2 study evaluating the safety and efficacy of avacincaptad for the treatment of GA found that monthly therapy of 2 mg (A) and 4 mg (B) significantly reduced GA growth rate.

From a safety perspective, sham treatment was associated with a 2.3% rate of new-onset neovascular AMD compared with rates of 9.0% and 9.6% in the 2-mg and 4-mg arms, respectively. It should be noted that unlike the FILLY study, GATHER1 did not enroll patients with a history of neovascular AMD in the fellow eye or patients with foveal-involving GA at baseline. A multicenter, phase 3 study, GATHER2, is currently enrolling approximately 400 patients and will randomly assign them to monthly 2 mg avacincaptad or sham. The primary endpoint will be assessed at 12 months. MORE CANDIDATES A multitude of additional therapeutic options are being investigated in earlier stage clinical trials which are pursuing both complement and noncomplement targets. NGM621 NGM621 (NGM Biopharmaceuticals) is a humanized IgG1 monoclonal antibody with a high affinity for binding to C3. It differs from pegcetacoplan in that it is not pegylated. In a phase 1 open-label study, no safety signals were detected.⁶ The ongoing multicenter, phase 2 CATALINA trial will evaluate the efficacy and safety of intravitreal injections of NGM621 compared with sham.⁶ Patients will receive 48 weeks of NGM621 or sham every 4 or 8 weeks. GT005 In 2015, Kavanagh et al found that physiologically low serum levels of complement factor I (CFI) may be associated with increased risk of advanced AMD.⁷ GT005 is an AAV-based gene therapy delivered via subretinal injection designed to induce expression of CFI. The phase 2 EXPLORE study is examining the safety and efficacy of GT005 in patients with GA with CFI mutations.⁸   The treatment group will receive two doses and will be compared with untreated controls. A forthcoming phase 2 study called HORIZON will examine GT005 in patients with and without CFI mutations, and will employ a structure similar to EXPLORE. GEM103 GEM103 is a native, fully functional recombinantly manufactured full-length complement factor H (CFH) that is identical to endogenous CFH. It is delivered via intravitreal injection. A phase 1 study has been completed.⁹ The 6-month phase 2 REGATTA study will examine the therapy in patients randomly assigned to monthly or EOM therapy. CONCLUSION Several promising candidates are in the pipeline for the treatment of GA. It should be noted that drug candidates discussed in this article do not represent an exhaustive examination of drugs in development, and there are other promising agents in earlier stages of development. 1. Anti-complement C5 Monotherapy Ineffective in Reducing Geographic Atrophy Lesion Size. Paper presented at: Angiogenesis, Exudation, and Degeneration 2016; Miami, FL.2. Holz FG, Sadda SR, Busbee B, et al. Chroma and Spectri Study Investigators. Efficacy and safety of lampalizumab for geographic atrophy due to age-related macular degeneration: Chroma and Spectri phase 3 randomized clinical trials. JAMAOphthalmol. 2018;136(6):666-677.3. Liao DS, Grossi FV, El Mehdi D, et al. Complement C3 inhibitor pegcetacoplan for geographic atrophy secondary to age-related macular degeneration: a randomized phase 2 trial. Ophthalmology. 2020;127(2):186-195.4. Holekamp N, Wykoff CC, Schmitz-Valckenberg S, et al. Natural history of geographic atrophy secondary to age-related macular degeneration: results from the prospective Proxima A and B clinical trials. Ophthalmology. 2020;127(6):769-783.5. IVERIC bio’s Zimura, a Novel Complement C5 Inhibitor, Met its Primary Endpoint and Reached Statistical Significance in a Phase 2b Randomized, Controlled Clinical Trial in Geographic Atrophy Secondary to Dry Age-Related Macular Degeneration [press release]. IVERIC bio; New York; October 28, 2019.6. NGM Bio Announces Initiation of Phase 2 CATALINA Study of NGM621 in Patients with Geographic Atrophy (GA) Secondary to Age-Related Macular Degeneration (AMD) [press release]. NGM Bio; South San Francisco; July 27, 2020.7. Kavanagh D, Yu Y, Schramm EC, et al. Rare genetic variants in the CFI gene are associated with advanced age-related macular degeneration and commonly result in reduced serum factor I levels. Hum Mol Genet. 2015;24(13):3861-3870.8. Gyroscope Therapeutics Announces Initiation of Phase II Programme Evaluating Its Investigational Gene Therapy, GT005, For Dry Age-Related Macular Degeneration [press release]. Gyroscope Therapeutics; London; August 13, 2020.9. Gemini Therapeutics Enrolls First Patient in Phase 2a Study of GEM103 for Dry Age-related Macular Degeneration [press release]. Gemini Therapeutics; Cambridge, MA; September 10, 2020.

---

CASE DISCUSSION

This discussion summarizes a case presentation and audience question-and-answer session with the panelists during a recent webinar. BY RISHI P. SINGH, MD; NATHAN STEINLE, MD; AND CHARLES C. WYKOFF, MD, PHD     Esther is an 88-year-old Hispanic woman with 20/30 VA in her right eye, with which she has difficulty reading. In her left eye, she has count fingers vision and an advanced brunescent cataract. Pigmentary changes and atrophy were detected on examination in both eyes (Figure). Esther is visiting your clinic for the first time based on a referral from a cataract surgeon who wants your opinion on whether cataract surgery should be performed on her left eye.

Figure. Pigmentary changes and atrophy are detected in both eyes; the patient had a brunescent cataract in her left eye.

Dr. Singh: The images in the Figure, particularly the OCT enface infrared images, are useful in a situation like this. Central atrophy is obvious in the left eye. The right eye has a small island of preserved retinal pigment epithelium cells centrally. Dr. Wykoff: In cases such as this, I almost always get OCT imaging and color fundus photography at baseline. Sometimes I will also order fundus autofluorescence (FAF) and a fluorescein angiogram if I suspect neovascularization is present. I am surprised that this patient can see 20/30 given the severity of her geographic atrophy (GA) in her right eye. Age-related macular degeneration (AMD) as presented here can be frustrating, as the paracentral GA in her right eye will likely progress. If future therapies can prevent GA growth in a patient like this, it would be very clinically useful. Dr. Steinle: AMD cases like this are difficult to predict regarding cataract surgery. Cataract surgery may result in some improved peripheral vision in the left eye; however, the central GA will limit the best corrected vision in the left eye. Patients like Esther may have a sense of false hope that cataract surgery will significantly improve their vision but given the foveal involvement of her GA in the left eye, that seems unlikely. Having Esther’s caregiver in the room with her during the exam will be useful, as he or she will need to understand how Esther’s condition will progress over time. In cases like this, FAF imaging is very helpful and easy to understand for both the patient and for caregivers. Dr. Wykoff: It’s important to remember that patients like Esther are frightened when they visit your office. Patients often think that they are going to be totally blind as their disease advances. I try to clarify the natural history of the disease process and reassure them that this process will very likely not lead to complete blindness. Dr. Singh:Would you recommend cataract surgery in this patient? Dr. Steinle: Yes, I would. I would try to limit expectations, but I would still proceed. I inform the patient that I expect cataract surgery to make everything “lighter and brighter” in the left eye, but that central vision will remain compromised.Dr. Wykoff:In many cases, eyes like this can experience substantial functional improvement. Dr. Singh: I agree—I’ve seen some of these patients gain up to 10 letters of vision. It’s also important to remember that visual function and patient satisfaction are not just measured by Snellen visual acuity. Our lab at the Cleveland Clinic, in fact, has a publication pending that evaluates visual outcomes in patientswith various levels of AMD. Even patients with center-involving GA have significant improvements in vision. Q |What do you tell a patient with extensive GA who has 20/30 VA and wants to drive?Dr. Wykoff:I encounter this situation often. I tell patients that I’m not going to take away their driver’s license, but that they are probably not safe to drive. I suggest that they rely on caregivers for transportation. Reminding patients that I as a retina specialist am not a primary eye care provider is useful in this situation. I advise that they return to their optometrist or general ophthalmologist, where formal visual fields and refractions can be performed, to manage this important issue. Dr. Singh: This is a difficult topic, as our patients value their independence. I sometimes use humor—“I bet you’re a better driver who gets fewer tickets than I do”—to defuse the discomfort of delivering bad news. I frame my response as a safety issue, and our patients generally respond well to that framework. Q | Some of the drug candidates for GA that you mentioned in your presentations could be approved for dosing every 1 or 2 months. How do you think this will work in the real world?Dr. Steinle: It’s important to recognize the structure of pipeline trials. Take as an example the DERBY and OAKS trials for pegcetacoplan. These phase 3 GA trials employ monthly and every-other-month dosing arms. If we end up seeing a dose-dependent response in those trials, then we’ll likely dose patients monthly. I’m not sure we will employ treat-and-extend regimens with any of the GA candidates in the pipeline. If that is the case, our clinics will face the challenge of a massive increase in patient volume as monthly GA patients begin to receive treatment alongside our treat-and-extend, as-needed, and monthly wet age-related macular degeneration patients, diabetic eye disease patients, and retinal vein occlusion patients. Dr. Singh: Every retina specialist is a tinker, and I suspect that if drugs to treat GA are granted regulatory approval for monthly administration, that we will shortly thereafter see clinical trials that examine the possibility of longer durations of administration. Dr. Wykoff worked on the TREX trial, which examined this exact question in wet AMD therapy.¹Dr. Wykoff: If the medications in clinical trials are proven safe and effective in the ongoing clinical development programs, additional work may be able to identify clinical and/or genetic factors that may be able to predict response and determine optimal retreatment intervals. Q | How will we select which patients are best suited for GA therapy?Dr. Steinle: FAF may be key in determining which GA patients are most likely to benefit from intervention. Patients with hyper-autofluorescence at the lesion border are most likely to experience lesion growth—and those patients are most likely to receive a benefit from a therapy designed to slow that growth in GA. Dr. Wykoff: Given the current inclusion and exclusion criteria for the ongoing phase 3 trial programs, we will not know how effective these drugs will be in patients without hyperfluorescent borders on FAF. Additional studies will need to be performed in order to learn how eyes with different phenotypes, such as no hyperfluorescence at the GA border, will perform. Lesion location may be key, too. Patients with foveal-involving lesions may be too far gone, as intervention at this point is not designed to arrest or reverse growth. It is only designed to slow growth. 1.Wykoff CC, Croft DE, Brown DM, et al. TREX-AMD Study Group. Prospective trial of treat-and-extend versus monthly dosing for neovascular age-related macular degeneration: TREX-AMD 1-year results. Ophthalmology. 2015;122(12):2514-2522.
